Solenoid valve EVR 20 - 032L1254

Connection size: 7/8" (female) x 7/8" (female)
,
Function: Normaly closed
,
Manual opening function: Yes
,
Coil model: None
Producer:
Danfoss
Line: EVR
Product code: 032L1254
Connection size:
7/8" (female) x 7/8" (female) 28 mm (female) x 28 mm (female) 1 1/8" (female) x 1 1/8" (female) 35 mm (female) x 35 mm (female) Flange connection
Function:
NO NC
Manual opening function:
No Yes
Coil model:
None BE230AS
  • Inlet connection type:
    Soldered
  • Inlet connection diameter:
    7/8"
  • Inlet flow speed [m/s]:
    0.35
  • Pressure drop [bar]:
Ask

Data

Technical data

Inlet connection type
Soldered, ODF (inch)
Inlet connection diameter
7/8"
Connection material
Copper
Net weight
[kg]
1.10
Gross weight
[kg]
1.47

Operating range

Maximum working pressure
[bar]
45
Maximum differential opening pressure of the valve
[bar]
38
Temperature range
[°C]
-40 — 80
Medium temperature range
[°C]
-40 — 105

Other

Function
Normaly closed
Manual opening function
Yes
Valve construction
Servo-diaphragm
Valve coil included
None

Dimensions

Inlet connection diameter
7/8"
Dimension L
[mm]
190
Dimension L1
[mm]
95
